Ultra-compact book mounting IPC based on Intel Apollo lake platform
Data Lifeguard Diagnostic for Windows. Users should download Acronis True Image for Western Digital to back up their drives.) WD Drive Utilities for Windows. Popular Hardware drivers downloads. 01 Microsoft® ODBC Driver 13.1 for SQL Server® - Windows, Linux, & macOS. The Microsoft ODBC Driver for SQL Server provides native connectivity from Windows, Linux, & macOS to Microsoft SQL Server and Microsoft Azure SQL Database. 02 Surface Pro 4 Drivers. To use this site to find and download updates, you need to change your security settings to allow ActiveX controls and active scripting. To get updates but allow your security settings to continue blocking potentially harmful ActiveX controls and scripting from other sites, make this site a trusted website. Downloads: Software, Drivers & User Guides The Latest Software & Drivers for all LabelWriters. Windows DYMO Connect for Desktop v1.3.2 Download. Not sure which software to choose? Click here The Latest Software & Drivers for all XTL TM Machines Windows DYMO ID™ v1.4 Download.
Models
BM120
Interfaces:
4 x Ethernet 10/100/1000Mbps
4 x USB 3.0
1 x RS232/422/485
1 x Display Port dual mode
2 x digital output
2 x digital input
Options:
UPS with external battery pack
BM121
Interfaces:
2 x Ethernet 10/100/1000Mbps
1 x Ethernet 10/100/1000Mbps 4 ports Switch
4 x USB 3.0
1 x Display Port dual mode
2 x digital output
2 x digital input
Options:
UPS with external battery pack
BM122
Interfaces:
2 x Ethernet 10/100/1000Mbps
2 x USB 3.0
4G Global modem
Wifi
1 x Display Port dual mode
2 x digital output
2 x digital input
Options:
UPS with external battery pack
Technical Data
Intel® Atom™ x5-E3930 1.3GHz (1.8GHz Burst), 2 cores / 2 threads, 2MB L2 cache, 14nm
Intel® Atom™ x7-E3950 1.6GHz (2.0GHz Burst), 4 cores / 4 threads, 2MB L2 cache, 14nm
- Intel® HD Graphics 500 integrated in x5-E3930, 400/550MHz
Intel® HD Graphics 505 integrated in x7-E3950, 500/650MHz
2GB or 4GB or 8GB (1 x LP-DDR4 soldered)
1 x onboard connector of M.2 size 2242 key B SSD SATA III
-
1 x RS232/422/485 (DB15M)
-
-
-
-
-
-
-
-
2 x Digital input
2 x Digital output
1 x Display Port V1.2 (no audio)
24VDC (18÷32VDC) isolated
Integrated UPS with external battery pack
Book or DIN rail mounting
Aluminium Alloy
100x100x78mm
0°÷50°C
Intel® Atom™ x5-E3930 1.3GHz (1.8GHz Burst), 2 cores / 2 threads, 2MB L2 cache, 14nm
Intel® Atom™ x7-E3950 1.6GHz (2.0GHz Burst), 4 cores / 4 threads, 2MB L2 cache, 14nm
- Intel® HD Graphics 500 integrated in x5-E3930, 400/550MHz
Intel® HD Graphics 505 integrated in x7-E3950, 500/650MHz
2GB or 4GB or 8GB (1 x LP-DDR4 soldered)
1 x onboard connector of M.2 size 2242 key B SSD SATA III
10/100/1000 Mbps Ethernet switch
4 x USB 3.0(Type-A)
-
-
-
-
-
-
-
-
2 x Digital input
2 x Digital output
1 x Display Port V1.2 (no audio)
24VDC (18÷32VDC) isolated
Remote power up inputPower status output
Integrated UPS with external battery pack
Book or DIN rail mounting
Aluminium Alloy
100x100x78mm
0°÷50°C
CE, UL 61010-1
Intel® Atom™ x5-E3930 1.3GHz (1.8GHz Burst), 2 cores / 2 threads, 2MB L2 cache, 14nm
Intel® Atom™ x7-E3950 1.6GHz (2.0GHz Burst), 4 cores / 4 threads, 2MB L2 cache, 14nm
- Intel® HD Graphics 500 integrated in x5-E3930, 400/550MHz
Intel® HD Graphics 505 integrated in x7-E3950, 500/650MHz
2GB or 4GB or 8GB (1 x LP-DDR4 soldered)
1 x onboard connector of M.2 size 2242 key B SSD SATA III
-
-
Standard
IEEE 802.11 a/b/g/n + Bluetooth V4.0 LE/V3.0+HS/ V2.1+EDR
Download Windows 10
Client / Access Point mode (Wi-Fi)
Asem Driver Download For Windows 10
64/128-Abits WEP, WPA, WPA2
802.11a: -73dBm / 802.11g: -74dBm /802.11n(2,4GHz): -72dBm@HT20,-69dBm@HT40 / 802.11n(5GHz): -69dBm@HT20,-68dBm@HT40 (Wi-Fi)<0.1% BER at -70dBm (Bluetooth)
2 x RP-SMA-F
2G/3G/4G LTE CAT4 Multibandup to 50Mbps upload / 150Mbps download
1 x SMA-F connector
1x SIM card socket push-push type
2 x Digital input
2 x Digital output
1 x Display Port V1.2 (no audio)
24VDC (18÷32VDC) isolated
Remote power up inputPower status output
Integrated UPS with external battery pack
Book or DIN rail mounting
Aluminium Alloy
100x100x78mm
0°÷50°C
CE, UL 61010-1
Personal area
Login to your personal area to download your restricted contents. If you don’t have am ASEM account yet, register here.
- Driver_ASEM_ApolloLake_Win10_1607.zip(451.62 MB)
- Driver_ASEM_ApolloLake_Win10_1809.zip(493.19 MB)
Asem Driver Download For Windows 10 Laptop
- BM12x.pdf(932.81 KB)
